SPECIFICATIONS

Brand Name: NoEnName_Null
Choice: yes
High-concerned chemical: None
Origin: Mainland China
Voltage: None
semi_Choice: yes

Material: Plastic
Pitch: 5.0mm
Poles: 2P 3P 4P
Screws: M2.5 steel Zinc plated
Contact: phosphor bronze Ni plated or stainless steel
Pin header: Copper,Tin plated
Housing: PBT,UL94V-0
Electrical
Rated voltage: 300V
Rated current: 15A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ/1000V
Withstanding Voltage: AC1500V/1Min
Wire range: 22-14AWG/2.5mm⊃2;
Mechanical
Temp.Range: -30°C~+120°C
MAX Soldering: +250°C for 5 Sec.
Torque: 0.5Nm(3.6lb.in)
Strip length: 4.5-5mm
